Rockwell Hardness Tester Clamp Type
(Portable or Benchtop Operation)

Initial Test Force: 10 kg
Major Test Force: 60 kg, 100 kg or 150 kg
Accuracy: +/-1.5HRC
Precision: +/-0.5 HR

Versatility: tests in the hand or on the desk; tests long, heavy specimens without cutting.
Portable Rockwell Hardness Tester is a great innovation in Rockwell hardness testers. Miniaturization and portability are realized without reducing testing accuracy. The smallest model weighs only 0.7kg, and the operation is similar to that of a micrometer.
The tester is suitable for testing a wide range of metals from soft metals to very hard alloys, including aluminum alloys, copper, copper alloys, mild steel, stainless steel, quenched steel, tempered steel, carbonized steel, and carbide. With a variety of anvils, the tester can be used to test sheets, cylinders and other materials of different shapes. It can also test the hardness of pipes from both inside and outside.

Portable Rockwell Hardness Testers read directly in 15 Rockwell scales: A, B, C, D, E, F, G, H, K, L, M, P, R, S, and V. The accuracy meets the requirement of GB/T230, ISO6508 and ASTM E18. The test is accurate, relatively fast and simple, with small indentation non-destructive to most specimens. Thus, it is suitable for one-by-one on -site inspection of batches of finished or semi-finished workpieces. The readings can be converted into HV, HB or tensile strength through conversion tables

Standard Package:
Tester, Bench stand, Diamond cone indenter, Carbide ball indenter, Rockwell test block, Flat Anvil, V anvil, Extensions, Carrying case



---
